> M915N200
Product Name:M915N200
Product introduction：NRP-M915N200 is a miniature UHF RFID reading and writing module that supports ISO 18000-6C protocol. It can be embedded in mobile devices such as handheld computers, PADs, and guns to expand the RFID reading and writing
product details
| Features | |
| 1 | Using high-performance radio frequency chips, stable and reliable operation |
| 2 | Small size, can be embedded in various devices such as handhelds and tablets |
| 3 | The output power can reach 30dBm, 1dBm step adjustable |
| 4 | Provide Demo, SDK, and development board, easy to develop |
| Performance parameter | |
| Frequency | 902~928MHz，865~868MHz, adjustable |
| Protocol | ISO 18000-6C（EPC C1 Gen 2） |
| Test software | Java Demo |
| SDK | Java SDK |
| Interface | UART, RS232 |
| Working voltage | ＜95%（25℃） |
| Working current | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Reading distance | 12m @ 8dBi gain antenna |
| Main market | United States, Canada, Europe, China, South Korea, Malaysia, etc |
| RF output | 15~30dBm |
| RF accuracy | ±1dB |
| RF flatness | ±0.2dB |
| Sensitivity | ＜-75dBm |
| Inventory speed | ≤50 tags/sec |
| Physical parameter | |
| Size | 35.5mm*55.5mm*5mm |
| Weight | 65g |
| Working TEMP | -25℃ ~ +80℃ |
| Storage TEMP | -30℃ ~ +80℃ |
| Antenna Interface | 1 SMA |
